KIT: Panasonic Toughbook 55 NO RF LITE Port Replication laptop vehicle docking station. Keyed alike (7160-0577-20) and LIND 120W Auto Power Adapter with Bare Wire Lead (7300-0461) | 7170-0971-00
Gamber-Johnson Toughbook 54 docking station kit includes Panasonic Toughbook 54 docking station with Lite Port Replication, No RF (7160-0577-20) and Lind external power supply (7300-0461).
ANTENNA PASS-THROUGH
- None
PORT REPLICATORS
- Ethernet - RJ45
- Fully Powered USB 3.0 (2) - 9 pin
- Serial - D-sub 9 pin
- Input Voltage - 15.6 V DC
- RF Switch
POWER SUPPLY
- Includes external Lind 120W auto bare wire leads power supply (7300-0461)
FEATURES
- Special docking connector pin protection – helps to prevent accidental pin damage by providing additional protection around and in between each docking pin
- Designed to MIL-STD 810G test procedures and complies with FCC Class A standards
- Small footprint - designed to maximize available space inside of vehicle
- Gamber-Johnson has worked with Panasonic to perform the appropriate tests needed to qualify a product as Toughbook Certified
- Rear-facing l/O ports, integrated cable strain relief system, and convenient cable management system
- Spring-loaded docking connector to ensure connectivity in the roughest terrain
- Front safety bracket and rear corners ensure proper alignment and docking connectivity
- Spring-loaded plate protects RF connector from damage when computer is not in the docking station. Plate draws back into the docking station when the computer is docked.
- This docking station accommodates the optional modular expansion area on the Toughbook 54/55 computer
- Special access area for smart card reader makes it easy to insert and eject card
- Push button latch with keyed lock for theft deterrence:
- Push the latch to release the docking connector
- Insert computer and push latch closed to dock computer
- Can be used with Motion Attachments with the VESA 75mm hole pattern only
- Rugged composite/steel construction with black powder coat finish for long-term durability
- Antenna switch position:
- Switch set toward outside of dock: Uses exterior antenna
- Switch set to inside of the dock: Uses laptop antenna
CERTIFICATIONS & TESTING
- Toughbook Certified
- RoHS, FCC
- C-Tick, E-Mark
- Vibration Testing: MIL-STD 810G 514.5
- Docking Handle Tested: 10,000 cycles
- SAE Standard J1455 Crash Test
WARRANTY
- 3-Year Limited Warranty
- Explore our extended warranty program
