Getac ZX70 Cradle Non-charging - 7160-1135-00 | 7160-1135-00

Getac ZX70 Cradle Non-charging — Gamber-Johnson part number 7160-1135-00.

Specifications

Features

• Designed for the Getac ZX70 tablet computer and backwards compatible with the Z710 tablet
• Easy to use one-handed operation:
• Insert bottom of computer into the cradle, push top of computer against latch button until latch engages
• To remove, push up on latch-button with thumb to disengage and pull computer out of the cradle
• Cradle design accommodates rotating hand strap (sold separately)
• Access to all tablet control buttons and USB port while tablet is cradled
• Optional lock (keyed alike) for theft deterrence
• Rounded edges to enhance personal safety
• Gamber-Johnson rugged construction and reliability
• Extremely light-weight composite/aluminum design
• VESA 75 mounting pattern

Product Details

• Model: ZX70
• Device OEM: Getac
• Warranty: 3-year Limited Lifetime Warranty, Extended Warranty/Gamber Guard Options Available
• Power Supply: Getac 22W Auto Power Adapter with Cigarette Lighter Connector (7300-0441), Getac 22W Auto Power Adapter with Bare End Connection (7300-0474), LIND 12-32V Material Handling Isolated Power Adapter (7300-0466), LIND 20-60V Material Handling Isolated Power Adapter (7300-0467)
• Testing Specifications: Getac Certified, Vibration Tested: MIL-STD 810G Operational/Non-operational, Shock Crash Hazard: SAE J1455, Mechanical Shock: 40g, Cycle Test: Latch, lock, and docking connector - 30,000 cycles, FCC, CE, RoHS Certified
• Antenna Pass-through: No RF
• Device Type: Tablet
• Industry: Fire/Rescue, Logistics, Material Handling, Public Safety, Utility
• Port Replication: NA
• Sub Type 1: Cradle
